COMFORT M4 an Insulated Curtain Wall System

Description

M4 is a thermal insulated system for structural curtain walls with hanging frames (stick type) for faster installation.

Advantages

Certificates

  • Seamless Design
  • Satisfactory Energy Efficiency
  • Increased Comfort level
  • Increased of security level
  • Increased static and functionality in extreme natural phenomena
  • Vast alternatives in custom solutions tailor made to the building
  • Ease of use with electric motion

Generic

AESTHETICS
Structural

Technical Characteristics

EXTERIOR VISIBLE WIDTH
55 mm

Performance

SECURITY OF VISIBLE LOAD
Design Load ± 2 KN/m1
WATER TIGHTNESS
R6, Window 9A
AIR PERMEABILITY
Class 4
WIND LOAD RESISTANCE
C4

Characteristics

TRANSOM DEPTH
47 – 154 mm
MULLION MAX INERTIA
501
TYPES OF TYPOLOGY
Fixed, Projected
MULLION DEPTH
49 – 139 mm
TRANSOMS MAX INERTIA
68
UF
from 3,7 W/m²K
TYPE OF HOLDING GLAZING
Structural Silicon
MAXIMUM WEIGHT
180 Kg

TYPOLOGIES

All available typologies

Hinged opening outward door

Hinged opening inward door

Projected outward window
