SMARTIA M65 a unitized façade system for maximum transparency

Description

SMARTIA M65 is a unitized curtain wall system ideal for high-rise buildings, which provides freedom in architectural design. The construction of the building’s envelope is done by assembling big panels consisted of many glass frames, either structural or with visible aluminium covers. Every unit can be freely designed by the architect, whilst the system guarantees easy and secure application.

Advantages

Certificates

  • High Energy Efficiency
  • Increased Comfort level
  • Increased of security level
  • Enhancement of Natural Light
  • Increased static and functionality in extreme natural phenomena
  • Ability to design custom solutions tailor made to the building
  • Ease of use with electric motion

Generic

AESTHETICS
Standard, Structural, Semi – Stuctural

Technical Characteristics

EXTERIOR VISIBLE WIDTH
65 mm

Performance

SECURITY OF VISIBLE LOAD
Load ±3 KN/m2
WATER TIGHTNESS
RE 1200
AIR PERMEABILITY
AE
WIND LOAD RESISTANCE
Design Load ± 2 KN/m1

Characteristics

TYPES OF TYPOLOGY
Fixed, Projected, Parallel Projected
TYPE OF INSTALLATION
Unitized
MULLION MAX INERTIA
320
MULLION DEPTH
176 mm
MAXIMUM WEIGHT
180 Kg
TRANSOM DEPTH
176 mm
UF
from 2,8 up to 3,7 W/m²K
TYPE OF HOLDING GLAZING
Pressure Plate

TYPOLOGIES

All available typologies

Tilt and turn window

Parallel and projected outward window

Hinged opening outward door

Hinged opening inward door

Projected outward window

Parallel projected outward window
